Parameters of wall mounted digital Signage parameter
specification | Model | Parameter |
Panel | LCD Size | 32”、43”、49”、55”、65” |
Panel Purchase Standard | A Grade |
Light Source | WLED |
Display Area | 32"：699 x 393mm
43"：930 x 523mm
49"：1096 x 616.5mm
55"：1210 x 681mm
65"：1430.5 x 805.5mm |
Resolution | 1920 x 1080pixels |
Contrast Ratio | 1200:1（typ.) |
Brightness | 32”: 380cd/m²(typ.)
43”、49”、55”: 380cd/m²(typ.)
65"：450cd/m²(typ.) |
Response Time | 8(Typ.)(G to G)(ms) |
Frequency | 60Hz |
Viewing Angles | 178°(H)/178°(V) |
Life Span | 30,000hrs(min.) |
Program | Operating System | Android 5.1 |
storage | RAM | 2G |
DDR | 8G or 16G |
Power Supply | Voltage | 100V~240V,50-60HZ |
Max. Power Consumption | 32"：≤105W
43"：≤120W
49"：≤120W
55"：≤160W
65"：≤160W |
Standby Power Consumption | ＜0.5W |
Environment | Working Temperature | 0℃～40℃ |
Storage Temperature | -10℃～60℃ |
Storage Humidity | 10%～90%RH Non-Condensing |
Working Humidity | 20%～85%RH Non-Condensing |
Maximum Use Time(hour/day) | 7x24 Hours |
Output Interface | EARPHONE | 1 |
HDMI | 1 |
Input Interface | USB 3.0 | 1 |
USB 2.0 | 1 |
WIFI | 1 |
LAN-RJ45 | 1 |
Structure | N.W(kg.) | TBD |
G.W(kg.) | TBD |
Bare Dimension(W x H x D) | 32"：769 x 463 x 72.7mm
43"：1005.5 x 599 x 62.2mm
49"：1173 x 692.5 x 74.1mm
55"：1287 x 757 x 63.7mm
65"：1504.5x 875.5 x 77.51mm |
Packing Dimension(W x H x D) | TBD |
Shell Material | Sheet Metal |
Shell Color | Aluminum Profile Silver/Black |
Language | OSD | English/ Chinese (multinational) |
