Embedded industrial display-parameter
technical parameter
LCD specifications | LCD specifications | A-gauge LCD module |
LCD size | 10.1Inch |
resolution ratio | 1280*800 |
Visual Angle | Full perspective |
Displays the area | 342.16*191.59mm |
Displays the proportion | 16:9 |
luminance | ≥250cd/m2 |
Backlight type | E-LED |
The corresponding time | 7ms |
system parameter | operating system | Android or windows |
Touch parameters | Touch control scheme | electric capacity G+G |
Touch media | Finger or capacitive touch pen |
Number of touch points | Touch at ten o'clock |
Touch precision | ≦2mm |
Touch-controlled drive | Free drive |
system function | Remote control function | Support for the remote control operation |
Mouse function | Support for mouse and keyboard use |
Timed function | Support for custom switch time |
Communication function | Support for WIFI / Ethernet optional 3G / 4G |
Camera function | Support for an optional camera |
Split screen function | Support for split-screen display through the messaging software |
software application | Support for the installation of third-party applications |
Picture play | Support for BMP, JPEG, PNG, GIF and many other formats |
Video play | Support for various formats such as wmv, a v, avi, flv, rm, rmvb, mpeg, ts, mp4 |
More multi-function | See the said operation statement for details |
Body parameters
| Body material | Aluminum profile frame + body hardware model + surface explosion-proof toughened glass |
Body color | Black, white and silver are optional |
Body size |
|
packing measurement |
|
Net weight / gross weight | 3KG/4KG |
Packaging material | neutro-packing |
operating requirement | way to install | Standard equipped with horizontal and vertical general wall hanger |
input voltage | AC110-220V |
Use power | ≦32W |
Standby power | ≦1W |
service environment | Temperature 20℃ ~60℃ / humidity 10%RH~90%RH |
Random accessories | AC Power cord * 1 WiFi Bar * 1 Remote Control * 1 Wall Mount * 1 Warranty Card * 1 Wall mount screw * 4 |
technical service | If you have doubts in the use process, please contact the manufacturer to provide technical services with technical services. |
