OLED transparent screen

parameter

face-plate

size

55

type

OLED face-plate

light transmittance

38%

Dynamic contrast

100000:1

scale

16:9

resolution ratio

1920*1080

Visual Angle

178/178/178/178

luminance

Autonomic regulation of the 150 – 400 cd/m2

Pixel Number (HxVx3)

6220800

colour gamut

108%

life span

For the next 30,000 hours

refresh rate

120HZ

joggle

import

USB joggle

HDMI joggle

The 3.5M audio interface

system

system parameter

Android, computer, monitor (optional)

Feature function

Transparent display, pixel point autonomous light control, ultra-high light transmittance

Power / environment

source

AC100-240V 50/60HZ

environment

Temperature: 0-40 degrees Humidity: 10% -80%

Size / weight

Displays the size

1209.6*680.1（MM）

Panel size

1221.5*699.35（MM）

weight

indeterminate

power dissipation

Power consumption value

190W

DPM

3W

shut down

0.5W

pack

appendix

Remote control, power cord, installation guide
